Descriere
1. Advanced inverter technology, simply circuit design, reduced size and
Weight, highly effective and energy saving;
2. Super strong electricity network compensation capabiliby, resistant to voltage
Pulsation, stable and reliable welding current;
3. Small DC are welding machine especially adopts proportional thrust control
Technology, single switch adjustment, simpler welding operation;
4. No load energy consumption less than 100W, Comparing with traditional
Welding machine, energy saving up to 50%;
5. Inverter frequency up to 100KHz, speedy dynamic response, easy to arc
Initiation, resistant to interference, stable arc, low welding noise, little welding
Spatter, deep melting pool, high welding strength, good welding quality;
6. Good thrust adjustment, resistant to welding electrode adtherence, applicable
For various acid and basic electrodes welding, cellulose electrodes downhand
Welding is available;
7. Applicable for welding of all kinds of ferrous metals such as low carbon steel,
Medium carbon steel and alloy steel, etc;
8. Digital display can exactly preset welding currnet;
9. Broadly used in the welding and field operation of oil pipeline, chemical
Industry, car, shipbuilding, boiler, power station construction, nuclear energy,
Spaceflight, military industry, industrial installation, bridge construction, ect;
Main Technology ParameterTable
Voltage: AC220V ± 15%(V)
Frequence: 50/60(Hz)
Rated Input Current: 32(A)
No-loading Voltage: 61(V)
Output Current: 30-200(A)
Cyclic Duration Factor: 60(%)
Weight: 8(kg)
Dimension Size: 371x153x232(mm)
Weight, highly effective and energy saving;
2. Super strong electricity network compensation capabiliby, resistant to voltage
Pulsation, stable and reliable welding current;
3. Small DC are welding machine especially adopts proportional thrust control
Technology, single switch adjustment, simpler welding operation;
4. No load energy consumption less than 100W, Comparing with traditional
Welding machine, energy saving up to 50%;
5. Inverter frequency up to 100KHz, speedy dynamic response, easy to arc
Initiation, resistant to interference, stable arc, low welding noise, little welding
Spatter, deep melting pool, high welding strength, good welding quality;
6. Good thrust adjustment, resistant to welding electrode adtherence, applicable
For various acid and basic electrodes welding, cellulose electrodes downhand
Welding is available;
7. Applicable for welding of all kinds of ferrous metals such as low carbon steel,
Medium carbon steel and alloy steel, etc;
8. Digital display can exactly preset welding currnet;
9. Broadly used in the welding and field operation of oil pipeline, chemical
Industry, car, shipbuilding, boiler, power station construction, nuclear energy,
Spaceflight, military industry, industrial installation, bridge construction, ect;
Main Technology ParameterTable
Voltage: AC220V ± 15%(V)
Frequence: 50/60(Hz)
Rated Input Current: 32(A)
No-loading Voltage: 61(V)
Output Current: 30-200(A)
Cyclic Duration Factor: 60(%)
Weight: 8(kg)
Dimension Size: 371x153x232(mm)
Fisa tehnica
M-5340
